22 Series

22 Series

Applications

  • High production capacity with increased ROI and reduced operating costs
  • Increased throughput with the ability to run up to 2 shifts
  • Deburring, edge breaking, edge radiussing, and surface finishing in one pass using multiple heads
  • Electronic photo tracking eyes for accurate abrasive belt tracking
  • Ability to customize configurations based on customer applications
  • Removal of vertical burrs from stamped, punched, laser, plasma, and water-jet cut parts
  • Dry operation
  • Small footprint

Specifications

  • Number of heads 1-3
  • Available in multiple configurations depending on customer application
  • Machine widths of 37″, and 52″
  • Electronic photo-eye abrasive belt tracking
  • Dust extraction available
  • Minikol Go-To bed position device
  • 15-45 fpm feed speed
  • Up to 40 HP main motors
  • 0-6″ machine opening
  • 8″ minimum part length
  • 6-10″ contact drums
  • 8″ brush head diameter
  • Oscillating brush heads
